What is a C11000 copper pipe?
Copper is a versatile metal that can be alloyed with many other metals to achieve specific properties. One of copper's main characteristics is its excellent electrical conductivity. Therefore, for applications requiring good conductivity, manufacturers often recommend C11000 copper bars. C11000 copper is also known as electrolytic tough copper.
As a common copper grade, C11000 electrolytic tough copper (ETP) is a general-purpose component in electrical applications. C11000 electrolytic tough copper has a minimum conductivity of 100% IACS and a purity requirement of 99.9%. While purity must be maintained above 99.9%, trace amounts of oxygen in electrolytic tough copper castings are not uncommon.
Typically, the oxygen content of this high-purity copper is expected to be between 0.02% and 0.04%. C11000 copper bars are typically used in the most demanding electrical applications, such as power and signal transmission.
Specification of C11000 Copper Bar
|
Standard & Material |
CDA 110 ETP, ASTM B124, ASTM B152, ASTM B187, ASTM B188, ASTM B272 |
|
HOLLOW RODS |
Min Bore Size 20 mm and Max OD 100 mm |
|
ROUND RODS |
8mm To 100 mm |
|
HEX |
10mm To 60mm |
|
SQUARE |
10mm To 60mm |
|
FLAT |
10mm Min Thickness and max Width 120mm |
|
BILLETS |
Up to 200 mm |
|
INGOTS |
As per Specification |
Applications of C11000 Copper Bar
Architectural Industry
Antimicrobial Applications
Electrical Industry
Telecommunications Industry
Equivelent Specifications of C11000 Copper Bar
|
End Product |
Specification |
|
Bar |
ASME SB133, ASTM B152, SAE J461, J463 |
|
Bar, Bus |
ASTM B187 |
|
Bar, Forging |
ASTM B124 |
|
Rod |
ASME SB133, MILITARY MIL-C-12166, SAE J461, J463 |
|
Rod, Bus |
ASTM B187 |
Chemical Composition of C11000 Copper Bar
|
Element |
Content (%) |
|
Cu |
99.90 |
Physical Properties of C11000 Copper Bar
|
Properties |
Metric |
Imperial |
|
Density |
8.89 g/cm3 |
0.322 lb/in3 |
|
Melting point |
1065 – 1083°C |
1949°F |
Mechanical Properties of C11000 Copper Bar
|
Properties |
Metric |
Imperial |
|
Hardness, Rockwell F (hard temper) |
80.0 |
80.0 |
|
Poisson's ratio |
0.34 |
0.34 |
|
Elastic modulus |
115 – 117 GPa |
16969 ksi |
Fabrication of C11000 Copper Bar
|
Joining Technique |
Suitability |
|
Brazing |
Good |
|
Butt Weld |
Good |
|
Capacity for Being Cold Worked |
Excellent |
|
Capacity for Being Hot Formed |
Excellent |
|
Coated Metal Arc Welding |
Not Recommended |
|
Forgeability Rating |
65 |
|
Gas Sheilded Arc Welding |
Fair |
|
Machinability rating |
20 |
|
Oxyacetylene Welding |
Not Recommended |
|
Seam Weld |
Not Recommended |
|
Soldering |
Excellent |
|
Spot Weld |
Not Recommended |
