What is H68 brass?
C26000 (Cartridge Brass) emerged from military applications during the industrial revolution, originally developed for ammunition manufacturing. Its 70/30 copper-zinc composition became the benchmark for applications requiring superior deep drawing capabilities and atmospheric corrosion resistance. The alloy gained widespread adoption in North American and European markets, becoming synonymous with high-quality brass applications.
H68 was developed within China's industrial framework as part of the comprehensive GB (Guobiao) standard system. With 68% copper content, it was engineered to provide optimal balance between performance characteristics and material cost, making it particularly suitable for high-volume manufacturing applications. H68 has gained recognition as "the most widely used brass variety" in Chinese industry.
Detailed Chemical Analysis
| Element | C26000 (ASTM B36) | H68 (GB/T 5231) | Difference Impact |
|---|---|---|---|
| Copper (Cu) | 68.5 – 71.5% | 67.0 – 70.0% | C26000: +1.5% average |
| Zinc (Zn) | Balance (28.5-31.5%) | Balance (30.0-33.0%) | H68: +1.5% average |
| Lead (Pb) | ≤ 0.07% | ≤ 0.05% | H68: Tighter control |
| Iron (Fe) | ≤ 0.05% | ≤ 0.10% | H68: More permissive |
| Aluminum (Al) | – | ≤ 0.002% | H68: Specified limit |
| Tin (Sn) | – | ≤ 0.002% | H68: Specified control |
| Antimony (Sb) | – | ≤ 0.005% | H68: Trace element control |
| Arsenic (As) | ≤ 0.02% | – | C26000: Dezincification control |
| Phosphorus (P) | ≤ 0.02% | ≤ 0.002% | H68: Stricter limit |
| Silicon (Si) | – | ≤ 0.007% | H68: Process control |
Microstructural Characteristics
| Property | C26000 | H68 | Significance |
|---|---|---|---|
| Phase Structure | Single α-phase | Single α-phase | Both excellent formability |
| Grain Size (ASTM) | 5-7 | 4-6 | H68: Slightly finer grain |
| Zinc Equivalent | 30.5% | 31.5% | H68: Higher equivalent |
| Phase Stability | Excellent | Excellent | Both stable at room temperature |
| Recrystallization Temp | 300-400°C | 310-420°C | Similar processing windows |
C26000 Advantages from Higher Copper:
Enhanced electrical conductivity (28% IACS vs 26% IACS)
Superior corrosion resistance in atmospheric conditions
Better thermal conductivity for heat transfer applications
Improved brazing and welding characteristics
Enhanced ductility for extreme forming operations
H68 Advantages from Optimized Composition:
Improved strength-to-cost ratio
Better dimensional stability during processing
Enhanced machinability due to refined microstructure
Optimized hot working characteristics
Reduced material cost while maintaining performance
Tensile Properties Comparison
| Condition | Property | C26000 | H68 | Units | Performance Difference |
|---|---|---|---|---|---|
| Annealed (O) | Tensile Strength | 300-380 | 295-375 | MPa | C26000: +5 MPa average |
| Yield Strength (0.2%) | 75-140 | 80-145 | MPa | H68: +5 MPa average | |
| Elongation | 60-68 | 65-70 | % | H68: +3% average | |
| Hardness (HV) | 60-85 | 55-80 | HV | C26000: +5 HV average | |
| Half Hard (H02) | Tensile Strength | 370-450 | 365-445 | MPa | Comparable |
| Yield Strength | 170-275 | 175-280 | MPa | H68: +5 MPa average | |
| Elongation | 25-35 | 28-38 | % | H68: +3% average | |
| Hard (H04) | Tensile Strength | 410-540 | 405-535 | MPa | Comparable |
| Yield Strength | 275-380 | 280-385 | MPa | H68: +5 MPa average | |
| Elongation | 15-25 | 18-28 | % | H68: +3% average |
Fatigue and Endurance Properties
| Test Condition | C26000 | H68 | Units | Application Impact |
|---|---|---|---|---|
| High Cycle Fatigue (10^7) | 140-160 | 145-165 | MPa | H68: Better spring applications |
| Low Cycle Fatigue (10^4) | 280-320 | 285-325 | MPa | Similar performance |
| Rotating Bending | 120-140 | 125-145 | MPa | H68: Slight advantage |
| Axial Fatigue | 100-120 | 105-125 | MPa | H68: Better for rods/bars |
| Corrosion Fatigue | 80-100 | 75-95 | MPa | C26000: Better in corrosive environments |
Temperature-Dependent Mechanical Properties
| Temperature | Property | C26000 | H68 | Performance Notes |
|---|---|---|---|---|
| -40°C | Tensile Strength | 420 MPa | 415 MPa | Both maintain ductility |
| Impact Resistance | High | High | No brittle transition | |
| 20°C | Tensile Strength | 340 MPa | 335 MPa | Reference condition |
| Modulus | 110 GPa | 108 GPa | Similar stiffness | |
| 100°C | Tensile Strength | 315 MPa | 310 MPa | Gradual reduction |
| Creep Resistance | Good | Good | Suitable for moderate temp | |
| 200°C | Tensile Strength | 280 MPa | 275 MPa | Limited applications |
| Oxidation | Moderate | Moderate | Protective atmosphere recommended | |
| 300°C | Tensile Strength | 245 MPa | 240 MPa | Short-term exposure only |
