Brass C28000 Tubes

Brass C28000 Tubes is one of the highest selling products from our production house. Brass C28000 is also known as Muntz metal. It is a yellow base copper-zinc alloy with light brown gold color having 62% to 65% of Cu and remaining Zn with very little addition of lead and iron. It has excellent tensile and yield strength and can elongate up to 25%. It has a unique color match to architectural bronze, C38500. It offers excellent resistance to spot and butt corrosion. It has excellent soldering and brazing ability. It also has proper flaring and bending properties, drawability, machinability, and is suitable for plating. It offers commendable mechanical properties like high ductility, high impact strength, high electrical and thermal conductivity, and low volatility under high vacuum. Application areas for Brass Alloy C28000 Tubing include heat exchangers, refineries, power plants, desalination plants, shipbuilding and repairs, condensers, ferrules distillers.

ASME SB135 Brass C28000 Tubes Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	EN	DIN CEN/TS 13388	JIS	BS
Brass C28000	2.0402	C28000	CuZn40	CW617N	C 3771	CZ 122

Specifications of Brass Alloy C28000 Tubes

Specifications	ASTM B135, B43, B587 / ASME B135, B43, SB587
Standard	DIN CEN/TS 13388 CW617N, ASTM B135-10, C 3771
Outer Diameter	4mm to 150mm
Wall Thickness	0.25mm to 8mm
Length	1m, 2m, 3m, 4m, 6m and as per requirement of clients
Cut Length	Single Random, Double Random & Cut Length
Type	Seamless
Form	Round, Square, Rectangular, Hydraulic Etc

Chemical Composition of Brass C28000 Tubes

Grade	Cu	Zn	Ni	Sn	Fe
Brass C28000	59-61%	Rest %	≤ 0.3%	≤ 0.3%	≤ 0.05 %

Mechanical Properties of Brass C28000 Tubing

Element	Density	Melting point-liquidus	Melting point-solidus	Elongation	Tensile strength	Yield strength
Brass C28000	8.39 gm/cm3	Metric - 904°C / Imperial - 1660°F	Metric - 899°C / Imperial - 1650°F	52	360 MPa, 52200 psi	140 MPa, 20300 psi

Copper products that GNEE can provide

copper pipe

Product Name	Straight Copper Pipe/Pancake Coil Copper Pipe/Capillary copper pipe
Material	C10100,C10200,C12000,C12200,C11000,T1,T2,T3,TP2,TU1,TU2,TU3,H62, H65,H70,etc
Standard	ASTM B280,ASTM B68,ASTM B75,ASTM B88 JIS H3300 EN12735,AS1571
Shape Type	Straight Round,Square,Rectangular,Coil,Oval,Half-Round
Wall Thickness	0.2-3mm
Out Diameter	3mm-100mm
Length	1M-6M or As your demand (Pancake copper tube usual length: 15 meters)
Cu	High Purity 99.9% Copper
Temper	Soft(M),Half Soft(M2) and Half Hard(Y2)
Surface Treatment	Bright and Clean
Package Type	Plastic Film With Plastic Caps on the both ends and Wooden Case Carton Package or as your demand
Application	Refrigerator,Condenser and Heat Exchange,Decoration,Water Tube,Precision Equipment etc

Get product catalog

copper rod/bar

Item	Straight copper rod/copper round bar
Standard	ASTM,DIN,BS,CDA,JIS,GB
Material	T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800, C10910,C10920,TP1,TP2,C10930,C11000,C11300,C11400,C11500, C11600,C12000,C12200,C12300,TU1,TU2,C12500,C14200,C14420, C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000, C26000,C27000,C27400,C28000,C33000,C33200,C37000,C44300, C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70600, C70620,C71000,C71500,C71520,C71640,C72200,etc.
Shape	Round,Square,Rectangular,etc.
Specifications	Diameter:3~200mm
Length	3m,5.8m, 6m, 11.8m, 12m, or as required.
Hardness	1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc
Surface	mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required.
Price term	EXW, FOB, CFR, CIF, etc.
Payment term	T/T
Package	Export standard package: bundled wooden box, suit for all kinds of transport, or be required.
Delivery time	According to order quantity
Application	A copper rod is a type of colored metal processing bar stock with high electrical conductivity. It is mainly divided into brass rods and copper rods. It is applied in water heating and bathroom fittings, small hardware, valves, marine pumps, atomizing device structural components, friction accessories, etc.
Contact	If any requirement please feel free to inform me at any time.

Get product catalog

copper plate/sheet/strip

Size	Width: 10mm to 2000mm, Thickness: 10mm to 500mm, Length: 0.5m to 12m, All sizes can be according to customer's requirements.
Hardness	1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard.
Surface	Polished,bright,oiled,hair line,brush,mirror,or as required
Export to	Ireland,Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Canada,USA, Brazil,Thailand,Korea,Italy,India,Egypt,Oman,Malaysia,Kuwait,Canada, Viet Nam, Peru
Package	Plastic film with Wooden case or wooden pallet
Delivery time	Prompt delivery or upon your order quantity.
Quality Control	Mill Test Certification is supplied with shipment,Third Part Inspection is acceptable.
Application	widely used inair conditioners,refrigerators,electric,solar water heater, polished pipe an be used in decorative,such as stair rail. Also can be made according to your required.
Shape	Round, Square, Oval, can be customized

Get product catalog

copper wire

Model Number	C11000, C10200, C12000, C12200 C26800 C27000 C35000 C38000 etc.
Color	Red Cppper , Brass
Hardness	1/16 hard, 1/8 hard, 3/8 hard, 1/4 hard, 1/2hard, full hard, soft, etc
Diameter	0.10mm-5.00mm
Insulation Material	Enameled
Certification	ISO9001
Advantages	High conductivity,Good solderability,High ductility
Coating	Double Layer or customized
Packing	Standard export package or seaworthy Package
Application	1. Pancake Coil for ACR, General Engineering Applications 2. LWC Coil for ACR, General Engineering Applications 3. Straight Copper Tubes for ACR and Refrigeration 4. Inner-grooved copper tube for ACR and Refrigeration 5. Copper Pipe for Transportation System of water, gas and oil 6.PE-coated copper tube for water/gas/oil transportation system 7.Semi-finished Copper tube for industrial applications

Get product catalog

copper CNC machined parts

Precision of piece:	+/-0.01mm
Roughness of piece:	Ra≤0.1
Quality standard:	DIN, ASTM, GOST, GB, JIS, ANSI, BS;
Drawing format:	JPEG,PDF,AI,PSD,DWG,DXF,IGS,STEP;
Products certification:	ISO9001:2008, CE, RoHS, SGS;
Dimension:	Dia.500mm or 850mm width
Available materials	Steel: carbon steel, alloy steel, stainless steel, 4140,20#,45# ,40Cr,20Cr ,etc
	Aluminum: AL6061,AL6063,AL6082,AL7075,AL5052 etc.
	Stainless steel: 201SS,301SS,304SS,316SS etc.
	Brass: C37700,C28000, C11000,C36000 etc
	Plastics: PTFE,PEEK,POM,PA,UHMW, NYLON
Surface treatment:	Steel parts	Stainless steel parts	Aluminum parts
	Galvanization	Polishing	anodized
	Black oxidation	Passivation	Sandblast anodized
	Nickel plating	Laser engraving	Colorful anodized
	Chrome plating	Sand blast	Brushed
	Heat treatment		Polishing
	Powder coated		Chrome plating

Get product catalog
