CuZn35Mn2Al1Fe1-C ( CC765S )
| Grade : |
CuZn35Mn2Al1Fe1-C |
| Number: |
CC765S |
| Classification: |
Copper-zinc alloy |
| Standard: |
EN 1982: 2008 Copper and copper alloys. Ingots and castings |
| Equivalent grades: |
Go here |
Chemical composition % of grade CuZn35Mn2Al1Fe1-C ( CC765S )
| A suffix -C is added to the designation to identify material in the form of castings |
| Fe |
Si |
Mn |
Ni |
P |
Al |
Cu |
Pb |
Sb |
Sn |
- |
| 0.5 - 2 |
max 0.1 |
0.5 - 3 |
max 6 |
max 0.03 |
0.5 - 2.5 |
57 - 65 |
max 0.5 |
max 0.08 |
max 1 |
Zn - remainder; Cu including Ni |
Mechanical properties of grade CuZn35Mn2Al1Fe1-C ( CC765S )
| Rm - Tensile strength (MPa) (GS) |
450 |
| Rm - Tensile strength (MPa) (GM) |
475 |
| Rm - Tensile strength (MPa) (GZ) or (GC) |
500 |
| Rp0.2 0.2% proof strength (MPa) (GS) |
170 |
| Rp0.2 0.2% proof strength (MPa) (GM) |
200 |
| Rp0.2 0.2% proof strength (MPa) (GZ) or (GC) |
200 |
| A - Min. elongation at fracture (%) (GS) |
20 |
| A - Min. elongation at fracture (%) (GM) or (GZ) or (GC) |
18 |
| Brinell hardness (HBW): (GS) or (GM) |
110 |
| Brinell hardness (HBW): (GZ) or (GC) |
120 |
Equivalent grades of grade CuZn35Mn2Al1Fe1-C ( CC765S )
Warning! Only for reference
EU
EN |
Germany
DIN,WNr |
| CuZn35Mn2Al1Fe1-C |
| 2.0592.01 |
| 2.0592.02 |
| 2.0592.03 |
| G-CuZn35Al1 |
| GK-CuZn35Al1 |
| GZ-CuZn35Al1 |
|
Casting process
| GS |
Sand casting |
| GM |
Permanent mould casting |
| GZ |
Centrifugal casting |
| GC |
Continuous casting |
| GP |
Pressure die casting |
Material conditions
| R |
Material condition designated by the minimum value of tensile strength requirement for the product with mandatory tensile strength and elongation requirements |
| H |
Material condition designated by the minimum value of hardness requirement for the product with mandatory hardness requirements |
Mechanical properties
| ReH |
Minimum yield strength / Mindestwert der oberen Streckgrenze / Limite d elasticite minimale |
| Rm |
Tensile strength / Zugfestigkeit / Resistance a la traction |
| A |
Minimum elongation / Mindestwert der Bruchdehnung / Allongement minimal |
| J |
Notch impact test / Kerbschlagbiegeversuch / Essai de flexion par choc |
|
