Copper C11000, or electrolytic tough pitch (ETP) copper, is a high-purity copper alloy containing 99.90% Cu and small impurities. It is characterized by very good electrical and thermal conductivity, corrosion resistance, and good ductility. The mechanical properties of C11000 pipes include tensile strength of about 200–400 MPa, yield strength of about 50–275 MPa, and elongation of 10–45%, varying with temper. The material is readily fabricated, soldered, and welded and thus suited to electrical, plumbing, and industrial uses demanding high conductivity and strength.
Copper C11000 Pipe Specifications
| Standard | ASTM B111 / ASTM B75 / ASTM B280 / ASTM B68 / ASME SB111 / ASME SB75 / ASME SB280 / ASME SB68 |
|---|---|
| Material | Copper |
| Outer Diameter(OD) | 4mm-150mm |
| Wall Thickness : | 0.25mm-8mm |
| Length | 1 meter-6 meter or as required |
| Types | Seamless Pipes, Pipe / Light Drawn Pipe / Light Annealed Pipe / Bright Pipe / Annealed Pipe, Annealed Pipe, Full Annealed Pipe, Hard Drawn Pipes |
| Application | 1. Pancake Coil for ACR, General Engineering Applications 2. LWC Coil for ACR, General Engineering Applications 3. Straight Copper Pipe for ACR and Refrigeration 4. Inner-grooved copper Pipe for ACR and Refrigeration 5. Copper Pipe for Transportation System of water, gas and oil 6. Semi-finished Copper Pipe for industrial applications |
Copper C11000 pipe Chemical Composition
| Grade | Cu | O |
| Copper C11000 | 99.90 min | 0.0400 |
Copper C11000 pipe Mechanical Properties
| Density (lb / cu. in.) | Electrical Resistivity (microhm-cm (at 68 Deg F)) | Mean Coeff Thermal Expansion | Modulus of Elasticity Tension |
| 0.323 | 12.2 | 9.4 | 17000 |
Copper C11000 Pipe Thickness Chart
| (mm) | Outside Diameter (mm) |
Table Y Half hard an annealed tube |
Table X Half hard light gauge tube |
Table Z Hard drawn thin wall tube |
|||
|---|---|---|---|---|---|---|---|
| Maximum Working Pressure (N/mm2) |
Thickness (mm) |
Maximum Working Pressure (N/mm2) |
Thickness (mm) |
Maximum Working Pressure (N/mm2) |
Thickness (mm) |
||
| 8 | 8 | 10.5 | 0.8 | 9.7 | 0.6 | 9.8 | 0.5 |
| 6 | 6 | 14.4 | 0.8 | 13.3 | 0.6 | 11.3 | 0.5 |
| 10 | 10 | 8.2 | 0.8 | 7.7 | 0.6 | 7.8 | 0.5 |
| 15 | 15 | 6.7 | 1 | 5.8 | 0.7 | 5 | 0.5 |
| 12 | 12 | 6.7 | 0.8 | 6.3 | 0.6 | 6.4 | 0.5 |
| 18 | 18 | 5.5 | 1 | 5.6 | 0.8 | 5 | 0.6 |
| 28 | 28 | 4.2 | 1.2 | 4 | 0.9 | 3.2 | 0.6 |
| 22 | 22 | 5.7 | 1.2 | 5.1 | 0.9 | 4.1 | 0.6 |
| 35 | 35 | 4.1 | 1.5 | 4.2 | 1.2 | 3 | 0.7 |
| 54 | 54 | 3.6 | 2 | 2.7 | 1.2 | 2.5 | 0.9 |
| 159 | 159.4 | 1.5 | 2 | 1.5 | 1.5 | ||
| 42 | 42 | 3.4 | 1.5 | 3.5 | 1.2 | 2.8 | 0.8 |
| 67 | 67 | 2.8 | 2 | 2 | 1.2 | 2 | 1 |
| 108 | 108.1 | 2.2 | 2.5 | 1.7 | 1.5 | 1.7 | 1.2 |
| 76.1 | 76.2 | 2.5 | 2 | 2.4 | 1.5 | 1.9 | 1.2 |
| 133 | 133.4 | 1.4 | 1.5 | 1.6 | 1.5 | ||
Size Chart Of Seamless Copper C11000 Pipe
| Outside diameter (OD) [in (mm)] |
Nominal size |
Inside diameter (ID) [in (mm)] |
||
|---|---|---|---|---|
| Type L | Type K | Type M | ||
| 1⁄2 (12.7) | 3⁄8 | 0.430 (10.922) | 0.402 (10.211) | 0.450 (11.430) |
| 3⁄8 (9.5) | 1⁄4 | 0.315 (8.001) | 0.305 (7.747) | |
| 2 5⁄8 (66.675) | 21⁄2 | 2.465 (62.611) | 2.435 (61.849) | 2.495 (63.373) |
| 5⁄8 (15.875) | 1⁄2 | 0.545 (13.843) | 0.528 (13.411) | 0.569 (14.453) |
| 7⁄8 (22.225) | 3⁄4 | 0.785 (19.939) | 0.745 (18.923) | 0.811 (20.599) |
| 3⁄4 (19.05) | 5⁄8 | 0.668 (16.967) | 0.652 (16.561) | 0.690 (17.526) |
| 1 1⁄8 (28.575) | 1 | 1.025 (26.035) | 0.995 (25.273) | 1.055 (26.797) |
| 1 5⁄8 (41.275) | 11⁄2 | 1.505 (38.227) | 1.481 (37.617) | 1.527 (38.786) |
| 1 3⁄8 (34.925) | 11⁄4 | 1.265 (32.131) | 1.245 (31.623) | 1.291 (32.791) |
| 2 1⁄8 (53.975) | 2 | 1.985 (50.419) | 1.959 (49.759) | 2.009 (51.029) |
| 3 1⁄8 (79.375) | 3 | 2.945 (74.803) | 2.907 (73.838) | 2.981 (75.717) |
Uses of Copper C11000 pipe
Copper C11000 tubes have widespread uses in various industries due to their high thermal and electrical conductivity, corrosion resistance, and durability. In the electrical industry, they are used in bus bars, wire, and conductive components. Plumbing and air conditioning systems rely on them for water and gas supply due to their anti-corrosive and biofouling resistances. Some of their applications in industry cover heat exchangers, condensers, and refrigerators. Moreover, they are applied in architectural buildings, ornamentation, and aquatic settings. Due to their high weldability and formability, they are suitable for custom fabrication in aerospace, automotive, and medical applications, which guarantee efficient performance under harsh conditions.
Products Description
Products Description
Copper products that GNEE can provide
|
Product name
|
Copper Pipe / Tube
|
|
Round copper pipe
|
Wall thickness: 0.2-120mm
|
|
Outside Diameter: 2mm~910mm
|
|
|
Rectangular copper pipe
|
Wall thickness: 0.2mm~910mm
|
|
Size: 2mm*4mm~1016mm*1219mm
|
|
|
Hardness
|
1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc
|
|
Standard
|
GB/T5231-2001.GB/T1527-2006.JISH3100-2006, JISH3250-2006, JISH3300-2006, ASTM-B152M-06, ASTM-B187, ASTM-B75M-02, ASTM-B42-02, ASTM-B370 /ASTM-B152 etc
|
|
Material
|
T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800,
C10910,C10920,TP1,TP2,C10930,C11000,C11300,C11400,C11500,
C11600,C12000,C12200,C12300,TU1,TU2,C12500,C14200,C14420,
C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,
C26000,C27000,C27400,C28000,C33000,C33200,C37000,C44300,
C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70600,
C70620,C71000,C71500,C71520,C71640,C72200,etc.
|
|
Usage
|
Pressure vessels, Heat exchangers, Cotter, pins, Rivets, Radiators, Gaskets, Roofing, Gutters
|
|
Package
|
Standard export package,suit for all kind of transport,or as required.
|
|
Material |
Copper, Brass, Bronze and special copper alloy |
|
|
Grade |
ASTM |
C10100,C11000,C12200,C21000,C22000,C23000,C24000,C26000, |
|
G/B |
TU1,T2,TP2,H96,H90,H85,H80,H70,H65,H63,H62,H59,HPb63-3, |
|
|
JIS |
C 1011,C 1100,C 1220,C3604,C 2100,C 2200,C 2300,C 2400, C 2600, |
|
|
BS |
Cu-OFE,C 101,Cu-DHP,CZ 125,CZ 101,CZ 102,CZ 103,CZ 106,CZ 107, CZ 108,CZ 109, CZ 123,CZ 124,CZ 121,CZ 111,CZ 133, Pb 104, |
|
|
DIN/ISO |
CuZn5,CuZn10,CuZn15,CuZn20,CuZn30,CuZn35,CuZn33,CuZn36, |
|
|
Shape |
Round, Square, Flat, Hexagon, Oval, Half-round or Customized |
|
|
Dimension |
Bar/Rod |
Standard(Diameter 5-160 mm) or Customized |
|
Wire |
Standard(Diameter 0.02-6 mm) or Customized |
|
|
Plate/Sheet |
Standard(T 0.2-50 mm/W 200-3000 mm/L 6000 mm) or Customized |
|
|
Strip |
Standard(T 0.05-1.5 mm/W 20-600 mm/L 20000 mm) or Customized |
|
|
Tube/Pipe |
Standard(OD 3-360mm/Wall thickness 0.5-50 mm) or Customized |
|
|
Standard |
GB/T,JIS,ASTM, ISO, DIN, BS, NF etc. |
|
|
Hardness |
1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard. |
|
|
Package |
Plastic film + Wooden case or as per customer requirement |
|
|
Surface |
Polished,bright,oiled,hair line,brush,mirror,or as required |
|
|
Deliver time |
According to order's quantity. |
|
|
Shipment |
By sea, by air, DHL, UPS, FedEx etc. or as required |
|
|
Application |
Electric light industry, machinery manufacturing, Building industry ,defense industry, and other fields Manufacturing industrial |
|
|
Product name |
Copper plate |
|||
|
Width |
500-2000mm or as customer request |
|||
|
Thickness |
0.2-120mm or as customer request |
|||
|
Length |
1000-6000mm or as customer request |
|||
|
Processing service |
Welding, stamping, cutting, bending, unwinding |
|||
|
Application |
Widely used in electrical industry, medical equipment, construction, chemical, |
|||
|
Export packing |
Standard Marine packaging or custom packaging |
|||
|
Price Terms |
FOB CIF CFR,or We can also go into detail |
|||
|
Product Name |
Copper Wire |
|
Standard |
AISI, ASTM, BS, DIN, EN, GB, JIS |
|
Diameter |
0.6mm / 0.8mm / 0.9mm / 1.0mm / 1.2mm / 1.6mm |
|
Thinckness |
0.12mm-3.0mm |
|
Cu Content (%) |
99.998% |
|
Alu-Zinc coating |
30-180g/m2 |
|
Material |
C21000,C22000,C22600,C23000,C24000,C26000,C26130,C26800,C27000,C27200,C27400, etc. |
|
Package |
Standard seaworthy export packing:
3 layers of packing, inside is kraft paper, water plastic film is in the middle and outside GI steel sheet to be covered by steel strips with lock, with inner coil sleeve |
|
Certification |
ISO, SGS, CE |
|
Delivery |
8-20 days |
|
Payment Terms |
T/T, LC, Western Union, Paypal, etc. |
|
MOQ |
1 Ton |
copper CNC machined parts
|
Processing |
CNC Turning,CNC Milling,Laser Cutting,Bending,Spining,Wire Cutting,Stamping, Electric Discharge Machining(EDM),Injection Molding,3D Printing,Rapid Prototype,Moulds etc. |
|
Materials |
Aluminum:2000 series,6000 series,7075,5052,etc. |
|
Stainlesss steel:SUS303,SUS304,SS316,SS316L,17-4PH,etc. |
|
|
Steel:1214L/1215/1045/4140/SCM440/40CrMo,etc. |
|
|
Brass:260,C360,H59,H60,H62,H63,H65,H68,H70,Bronze,Copper |
|
|
Titanium:Grade F1-F5 |
|
|
Plastic:Acetal/POM/PA/Nylon/PC/PMMA/PVC/PU/Acrylic/ABS/PTFE/PEEK etc. |
|
|
|
Anodized,Bead Blasted,Silk Screen,PVD Plating,Zinc/NickI/Chrome/Titanium Plating, |
|
Tolerance |
+ / - 0 . 0 1 m m |
|
Surface |
Min Ra 0.1~3.2 |
|
CERTIFICATE |
ISO9001:2015,IOS14001：2015,ROSH. |
Why choose us?
Since our establishment in 2008, our company has specialized in the production and export of copper products. We utilize advanced production lines and a comprehensive quality control system. From raw materials to finished products, every step is rigorously inspected using precision instruments (such as spectrometers, metallographic microscopes, and conductivity testers) to ensure that our products meet international standards for composition, dimensions, and performance. We are committed to providing high-quality, high-precision copper products and reliable service to our global customers.
