CuNi9Sn2 ( CW351H )
| Grade : | CuNi9Sn2 |
| Number: | CW351H |
| Classification: | Cupper alloy |
| Density | 8.9 g/cm ³ |
| Standard: | EN 1652: 1998 Copper and copper alloys. Plate, sheet, strip and circles for general purposes EN 1654: 1998 Copper and copper alloys. Strip for springs and connectors EN 13148: 2001 Copper and copper alloys. Hot-dip tinned strip |
| Equivalent grades: | Go here |
Chemical composition % of grade CuNi9Sn2 ( CW351H )
| Fe | Mn | Ni | Pb | Zn | Sn | Others | - |
| max 0.3 | max 0.3 | 8.5 - 10.5 | max 0.03 | max 0.1 | 1.8 - 2.8 | total 0.1 | Cu - remainder |
Mechanical properties of grade CuNi9Sn2 ( CW351H )
| Rm - Tensile strength (MPa) (R340) | 340-410 |
| Rm - Tensile strength (MPa) (R380) | 380-470 |
| Rp0.2 0.2% proof strength (MPa) (R340) | 250 |
| Rp0.2 0.2% proof strength (MPa) (R380) | 200 |
| A - Min. elongation at fracture (%) (R340) | 40 |
| A - Min. elongation at fracture (%) (R380) | 10 |
| A - Min. elongation Lo = 50mm (%) (R340) | 30 |
| A - Min. elongation Lo = 50mm (%) (R380) | 8 |
| Vickers hardness ( HV): (H075) | 75 - 110 |
| Vickers hardness ( HV): (H110) | 110 - 150 |
Properties CuNi9Sn2
| Modulus of elasticity = 140 kN/mm ² Electrical conductivity = 6 MS/m; |
Equivalent grades of grade CuNi9Sn2 ( CW351H )
Warning! Only for reference
| EU EN |
Germany DIN,WNr |
||
| CuNi9Sn2 |
|
Casting process
| GS | Sand casting |
| GM | Permanent mould casting |
| GZ | Centrifugal casting |
| GC | Continuous casting |
| GP | Pressure die casting |
Material conditions
| R | Material condition designated by the minimum value of tensile strength requirement for the product with mandatory tensile strength and elongation requirements |
| H | Material condition designated by the minimum value of hardness requirement for the product with mandatory hardness requirements |
Mechanical properties
| ReH | Minimum yield strength / Mindestwert der oberen Streckgrenze / Limite d elasticite minimale |
| Rm | Tensile strength / Zugfestigkeit / Resistance a la traction |
| A | Minimum elongation / Mindestwert der Bruchdehnung / Allongement minimal |
| J | Notch impact test / Kerbschlagbiegeversuch / Essai de flexion par choc |
|
